Combi B 90

Partly changeable safe deposit lock with dead bolt.

Combination lock 17,600, key lock 46,7000 theoretical variations.

This safe deposit lock combines the features of a combination lock and a key lock. Only after a valid combination has been set using the three knobs, can the user open the lock with the key. The combination is changed via a slide unit at the back of the lock.

3-way closure is available as an option.

Request a Quote

EN 1300, ECB-S, VdS class 2, VdS approval numbers: lock system M102323, bolt switch G113062

8 digits (ID + 6 digits), 1 Master code, 1 Manager, 90 User codes, 1 Courier code

User with ID 01 can be configured to be a manager who can manage the users

Configurable that the Manager can set opening delay parameters

Configurable that the Manager can activate or deactivate the Dual Mode

Audit with 970 entries

Product Details

Approvals/Certificates

Without any approvals/certificates

Lock

Combination lock
- 3 die-cast knobs, nickel-plated, 26 setting marks (A-Z) each
- Set combination can be seen at back of lock
- Combination change via slide unit at back of the lock
Key lock
- 6 levers, electrolytic galvanised steel
- Key retained when in open position
Die-cast lock case and bolt, throw 11 mm
Suitable for doors from 7 to 15 mm

Admissible mounting positions

Right hand lock, opening clockwise

Product Downloads

Zertifikat / Certificate VdS 82132 (EN / FR)

2.37 MB

Zertifikat / Certificate ECB-S (EN)

100.99 KB

Zertifikat / certificate / certificat CNPP / A2P CB90 (EN / FR)

900.59 KB
